SPECIFICATION |
||
| Specs | Chipset | Ambarella |
| Sensor | CMOS sensor | |
| LCD | 2-inch LCD | |
| Lens | F/NO=2.5, 155° wide angle lens? | |
| Waterproof&dustproof? | IP66 | |
| Drop test | 2M | |
| Memory | Default 32G (up to 128G) | |
| Working temperature | -30℃~55℃ | |
| Storage Temperature | -40℃~55℃ | |
|
Interface & Function |
Speaker | Built-in |
| Microphone | Built-in | |
| Earphone | With walkietalkie | |
| Audio/video input interface | Mini USB 2.0 | |
| Built-in? WIFI | Optional | |
| Live video transmission | Work with Wi-Fi | |
| On-vehicle function | Fixed on vehicle with recharge and intercom function | |
| Walkietalkie compatibility | Analog compatible | |
| Photo | Output pixel | 33MP max |
| Shutter | Electronic | |
| Focusing | FF (F.No.=2.5) | |
| Focal distance | 50cm-∞ | |
| Exposure control | Auto | |
| File format | JPG | |
|
Video & Audio |
Video resolution | SHD:2304X1296(30fps) |
| FHD:1920X1080(30fps) | ||
| HD:1280X720(60fps)? | ||
| HD:1280X720(30fps) (default) | ||
| WVGA：848 x480（30fps) | ||
| Video (compression) format | MOV(H.264) | |
| Continuous video recording time |
Around
8 hours (HD) Around? 10 hours (WVGA) |
|
| Audio format in audio mode | WAV | |
| Continous audio recording time | Around 10 hours | |
|
Operation & UI |
LED | power-on, recharge, video recording, audio recording |
| Night-vision distance | Strengthen energy-saving IR LED with 15 meters visual range | |
| Photosensitive reaction | working with? automatical IR cut? | |
| IR switching way | Auto? | |
| Playback | All files playback | |
| Photo taking while recording | YES | |
| Watermark | Year/Month/Day/Hour/Minute/Second | |
| OSD languages | English/Chinese | |
| File generated format | PICTxxxx. JPG/WAV/MOV | |
| Size | Size(mm) | 94mm(L)×60mm(W)×30mm(H) |
| Weight | Around 141g(battery included) | |
| Power Supply | Built-in battery | 2800mAh |
| Recharging time | around 5 hours | |
| Standby time | around 20 hours | |
| Recharging way | adapter/USB/car charger | |
| Cable | USB cable | |
| Accessories | Standard | Crocodile clip/adapter/USB cable/CD(user manual included)/Quick operation guide |
| Optional | Charging station/ car mount/ external camera | |
? ? ? ? ? ??? ? ? ? ? ??? ? ? ? ? ?
